NFPA 79, 2024 Edition: Electrical Standard for Industrial Machinery
NFPA規格 79 2024年版: 産業機械用電気規格
発行元 National Fire Protection Association (NFPA)
発行年/月 2024年2月
装丁 ペーパー
ページ数 115 ページ
発送予定  1-2営業日以内に発送します
※当ウェブ・ショップに掲載のない規格につきましては、別途お問合せ下さいませ。
※掲載の規格は、当ウェブ・ショップに掲載時点で確認できた最新版でございます。 最新の発行状況につきましては受注時に改めて確認をさせて頂きますので予めご了承下さい。




Description

NFPA 79, Electrical Standard for Industrial Machinery, includes updates for requirements that deal with the full spectrum of equipment-from single-motored drill presses to complex automated manufacturing systems. This must-have companion to both NFPA 70®, National Electrical Code® (NEC®), and NFPA 70E®, Standard for Electrical Safety in the Workplace®, is newly revised to contend with new technologies and their effects on electrical safety. Help ensure essential protection for operators, equipment, facilities, and work in progress.

Highlights
The 2024 edition includes:
- New section in Chapter 4 regarding cybersecurity considerations
- Clarification on the use of control circuit conductor protection in Chapter 7
- Metric measurements revised to soft conversions in Chapter 11 to avoid potential negative safety impact
- Removal of the term hazardous from Chapter 7 and replacement of the term conductor with wire in Chapter 12
- Revisions to the use of proximity switches and listed splicing wire connectors
- Updated Chapter 15 to clarify the application of externally supplied lighting circuit overcurrent protection



Contents:

Chapter 1 Administration
1.1 Scope.
1.2 Purpose.
1.3 Application.
1.4 Specific Provisions Other Than NFPA 79.
1.5 Specific Provisions Not Made in Relation to NFPA 70.
1.6 State of the Art.

Chapter 2 Referenced Publications
2.1 General.
2.2 NFPA Publications.
2.3 Other Publications.
2.4 References for Extracts in Mandatory Sections.

Chapter 3 Definitions
3.1 General.
3.2 NFPA Official Definitions.
3.3 General Definitions.

Chapter 4 General Requirements and Operating Conditions
4.1 General Considerations.
4.2 Electrical Components and Devices.
4.3 Installation and Use of Listed or Labeled Equipment.
4.4 Electrical Supply.
4.5 Physical Environment and Operating Conditions.
4.6 Transportation and Storage.
4.7 Provisions for Handling.
4.8 Installation and Operating Conditions.
4.9 Available Fault Current.
4.10 Cybersecurity.

Chapter 5 Disconnecting Means
5.1 Machine Supply Circuit and Disconnecting Means.
5.2 Additional Disconnecting Means.
5.3 Means for Removal of Power for Prevention of Unexpected Start-Up.

Chapter 6 Protection from Electrical Hazards
6.1 General.
6.2 Basic Protection.
6.3 Fault Protection.
6.4 Protection by the Use of Protective Extra Low Voltage (PELV) or Class 2 Circuits.
6.5 Protection Against Residual Voltages.
6.6 Arc Flash Hazard Warning.

Chapter 7 Protection of Equipment
7.1 General.
7.2 Overcurrent Protection.
7.3 Overload Protection of Motors.
7.4 Abnormal Temperature Protection.
7.5 Protection Against Supply Interruption or Voltage Reduction and Subsequent Restoration.
7.6 Overspeed Protection.
7.7 Phase Sequence Protection.
7.8 Protection Against Overvoltages Due to Lightning and Switching Surges.
7.9 Power Factor Correction Capacitor Overcurrent Protection.

Chapter 8 Grounding and Bonding
8.1 General.
8.2 Equipment Grounding Conductors and Bonding Jumpers.
8.3 Control Circuits.
8.4 Lighting Circuits.

Chapter 9 Control Circuits and Control Functions
9.1 Control Circuits.
9.2 Control Functions.
9.3 Protective Interlocks.
9.4 Control Functions in the Event of Failure.

Chapter 10 Operator Interface and Control Devices
10.1 General.
10.2 Pushbutton Actuators and Color Graphic Interface Devices.
10.3 Indicator Lights and Icons of Color Graphic Interface Devices.
10.4 Illuminated Pushbuttons.
10.5 Rotary Control Devices.
10.6 Start Devices.
10.7 Devices for Stop and Emergency Stop.
10.8 Devices for Emergency Switching Off.
10.9 Displays.

Chapter 11 Control Equipment: Location, Mounting, and Enclosures
11.1 General Requirements.
11.2 Location and Mounting.
11.3 Degrees of Protection.
11.4 Enclosures, Doors, and Openings.
11.5 Spaces Around Control Cabinets and Compartments.

Chapter 12 Conductors, Cables, and Flexible Cords
12.1 General Requirements.
12.2 Conductors.
12.3 Insulation.
12.4 Conductor Markings.
12.5 Conductor Ampacity.
12.6 Conductor Sizing.
12.7 Conductors and Cables Used for Flexing Applications.
12.8 Cords.
12.9 Special Cables and Conductors.

Chapter 13 Wiring Practices
13.1 Connections and Routing.
13.2 Identification of Conductors.
13.3 Wiring Inside Enclosures.
13.4 Wiring Outside Enclosures.
13.5 Raceways, Support Systems (Cable Supports), Connection Boxes, and Other Boxes.

Chapter 14 Electric Motors and Associated Equipment
14.1 General Requirements.
14.2 Conductors Supplied from Separate Disconnecting Means.
14.3 Reserved.
14.4 Motor Dimensions.
14.5 Motor Mounting and Compartments.
14.6 Criteria for Selection.
14.7 Protective Devices for Mechanical Brakes.
14.8 Direction Arrow.
14.9 Marking on Motors.
14.10 Motor Controllers.

Chapter 15 Accessories and Lighting
15.1 Accessories.
15.2 Local Lighting of the Machine and Equipment.

Chapter 16 Marking and Safety Signs
16.1 General.
16.2 Safety Signs for Electrical Enclosures.
16.3 Function Identification.
16.4 Machine Nameplate Data.
16.5 Equipment Marking and Identification.

Chapter 17 Technical Documentation
17.1 General.
17.2 Information to Be Provided.
17.3 Requirements Applicable to All Documentation.
17.4 Basic Information.
17.5 Installation Diagram.
17.6 Block (System) Diagrams and Function Diagrams.
17.7 Circuit Diagrams.
17.8 Operating Manual.
17.9 Maintenance Manual.
17.10 Parts List.

Chapter 18 Testing and Verification
18.1 General.
18.2 Continuity of the Effective Ground-Fault Current Path.
18.3 Insulation Resistance Tests.
18.4 Voltage Tests.
18.5 Protection Against Residual Voltages.
18.6 Functional Tests.
18.7 Retesting.

Chapter 19 Servo Drives and Motors
19.1 Overcurrent Protection for Drives and Servo Motors.
19.2 Motor Overtemperature Protection.
19.3 Servo Drive System Conductors.
19.4 Contactor.
19.5 Cable Shield.

Annex A Explanatory Material
Annex B Inquiry Form for the Electrical Equipment of Machines
Annex C Examples of Industrial Machines Covered by NFPA 79
Annex D Technical Documentation
Annex E Device and Component Designations
Annex F Electrical Enclosure Ratings: Type-Rating Versus IP-⁠Rating
Annex G Kilowatt Outputs with Horsepower Equivalents
Annex H Minimizing the Probability of Control Function Failure
Annex I AWG Conductor Cross-Reference Table
Annex J Electrical Terms Defined
Annex K Informational References
